Description
Turn case design on its head
Simplified, but not simple
Two tone exterior design extrudes elegance with quality feel constructed of steel and glass.
The brilliance of upside down layout
Unlike traditional cases, the graphics card cooling fans face up to more effectively intake fresh air from top of the case for improved and consistent performance.
Positive pressure design
With positive pressure design, heat will be exhausted through vents as well as preventing dust accumulation over time.
Integrated graphics card supporter, the savior of graphics cards
Included adjustable graphics card supporter helps to distribute weight of graphics card. This helps prevent accidental motherboard slot damage or card sagging.
Perfect dust prevention
Three full coverage filters with positive pressure design help prevent performance degradation caused by dust accumulation over time.
Wide variety of cooling options
Support up to two 280mm liquid cooling radiators,
a breakthrough from typical Micro-ATX cases.
Front：120/140mm fan x 2, or 240/280mm radiator x 1
Top ：120/140mm fan x 2, or 240/280mm radiator x 1
Rear ：120mm fan x 1, or 120mm radiator x 1
a breakthrough from typical Micro-ATX cases.
Front：120/140mm fan x 2, or 240/280mm radiator x 1
Top ：120/140mm fan x 2, or 240/280mm radiator x 1
Rear ：120mm fan x 1, or 120mm radiator x 1
High compatibility beyond expectations
Support dual graphics card installation
Support graphics card up to 370mm in length
Support graphics card up to 370mm in length
Support power supply up to 220mm in length
Support CPU air cooler up to 168mm in height
Product Specifications
Model No.
SST-RL08BR-RGB (Black & red + RGB fan + tempered glass)
Material
Steel + mesh front panel, tempered glass side panel, steel body
Motherboard
Drive bay
External
- 5.25” x 1
Internal
- 3.5" x 3 (compatible with 2.5") , 2.5" x 2
Cooling system
Front
- 2 x 140mm / 120mm fan slot (2 x 120mm RGB fan included)
Rear
- 1 x 120mm fan
Top
- 2 x 140mm / 120mm fan slot
Radiator support
Front
- 120mm / 140mm / 240mm / 280mm x 1*
Rear
- 120mm x 1
Top
- 120mm / 140mm / 240mm / 280mm x 1*
Limitation of CPU cooler
168mm
Expansion slot
5
Limitation of expansion card
With front 140mm fan installed, up to 13.6" (345mm) in length, width restriction –6.85" (174mm)**
Power supply
Optional PS2 (ATX)
Limitation of PSU
160mm ~ 220mm
Front I/O port
USB 3.0 Type-A x 2
Audio x 1
MIC x 1
Audio x 1
MIC x 1
Dimension
217mm (W) x 391mm (H) x 433mm (D), 36.7 Liters
8.54" (W) x 15.39" (H) x 17.05" (D), 36.7 Liters
8.54" (W) x 15.39" (H) x 17.05" (D), 36.7 Liters
Net weight
6.24 kg
* For 280mm radiators, we recommend total thickness of 30mm or less
**Expansion slots 3, 4, and 5 may have different length restrictions depending on optical drive installed, please refer to manual for more information.
**Expansion slots 3, 4, and 5 may have different length restrictions depending on optical drive installed, please refer to manual for more information.
