| Model Number |
MB500-KGNN-S00 |
|
|
|
| Materials - Outlook |
Steel, Mesh, Plastic |
|
| Materials - Side Panel |
Tempered Glass |
|
| Dimensions (L x W x H) |
505 x 209 x 499mm (incl. Protrusions), 491 x 209 x 499mm (excl. Protrusions) |
|
|
|
| Motherboard Support |
Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature) |
|
|
|
|
|
| 2.5" / 3.5" Drive Bays (Combo) |
2 |
|
|
|
| I/O Panel |
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button |
|
| ARGB Controller |
ARGB/PWM Hub |
|
| Pre-installed Fans - Top |
N/A |
|
| Pre-installed Fans - Front |
1x 120mm SickleFlow PWM ARGB |
|
| Pre-installed Fans - Rear |
1x 120mm MF120 non-LED Fan |
|
| Fan Support - Top |
3x 120mm, 2x 140mm |
|
| Fan Support - Front |
3x 120mm, 2x 140mm |
|
| Fan Support - Rear |
1x 120mm |
|
| Radiator Support - Top |
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm) |
|
| Radiator Support - Front |
120mm, 140mm, 240mm, 280mm, 360mm |
|
| Radiator Support - Rear |
120mm |
|
| Clearance - CPU Cooler |
165mm / 6.49" |
|
| Clearance - PSU |
180mm/7.08", (295mm / 11.61” with HDD cage removed) |
|
| Clearance - GFX |
410mm/16.1" |
|
| Dust Filters |
Bottom, Front, Top |
|
|
|
|
|
|
|
|
|
