| PERFORMANCE |
| Processor |
Intel Core Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB |
| AI PC Category[1] |
AI-Powered Gaming PC |
| NPU |
Integrated Intel AI Boost, up to 13 TOPS |
| Graphics |
NVIDIA GeForce RTX 5070 Ti 12GB GDDR7, Boost Clock 2220MHz, TGP 140W, 992 AI TOPS |
| Chipset |
Intel HM870 Chipset |
| Memory |
2x 16GB SO-DIMM DDR5-5600 |
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable |
| Max Memory |
Up to 32GB DDR5-5600 offering |
| Storage |
1TB SSD M.2 2242 PCIe 4.0x4 NVMe |
| Storage Slot |
Two M.2 2280 PCIe 4.0 x4 slots |
| Max Storage Support |
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
• M.2 2280 SSD up to 1TB |
| Optical |
None |
| Card Reader |
None |
| Audio Chip |
High Definition (HD) Audio, Realtek ALC3306 codec |
| Speakers |
Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio |
| Microphone |
2x, Array |
| Camera |
5.0MP with E-shutter |
| Battery |
80Wh |
| Power Adapter |
300W Slim Tip (3-pin) |
| Special Features |
AI Chip: LA3 |
| DESIGN |
| Display |
16" WQXGA (2560x1600) OLED 500nits (typical) / 1100nits (peak) Glossy, 100% DCI-P3, 240Hz, DisplayHDR True Black 1000, Dolby Vision, G-SYNC |
| Touchscreen |
None |
| Screen-to-Body Ratio |
91.7% AAR (active area ratio) |
| Color Calibration |
Factory Color Calibration |
| Pen |
Pen Not Supported |
| Keyboard |
24-Zone RGB Backlit, English |
| Touchpad |
Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
| Dimensions (WxDxH) |
364.38 x 268.06 x 21.69-25.95 mm (14.35 x 10.55 x 0.85-1.02 inches) |
| Weight |
Around 2.42 kg (5.34 lbs) |
| Case Color |
Eclipse Black |
| Case Material |
Aluminium (Top), PC-ABS (Bottom) |
| Surface Treatment |
Anodizing Sandblasting |
| SOFTWARE |
| Operating System |
Windows 11 Home Single Language, English |
| Bundled Software |
Office Home 2024 + Lenovo AI Now |
| CONNECTIVITY |
| WLAN + Bluetooth[2] |
Wi-Fi 7, 802.11be 2x2 + BT5.4 |
| WWAN |
Non-WWAN |
| Ethernet |
100/1000M (RJ-45) |
| Standard Ports[3] |
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort 2.1
1x USB-C (Thunderbolt 4 / USB4 40Gbps), with DisplayPort 2.1
1x HDMI 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector |
| Docking |
Various docking solutions supported via Thunderbolt or USB-C.
For more compatible docking solutions, please visit <a href="https://psref.lenovo.com/accessories/?category=Docking&system=Legion%20Pro%205%2016IAX10H" target="_blank"><u>Docking for Legion Pro 5 16IAX10H</u></a> |
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0 Enabled |
| Fingerprint Reader |
None |
| Other Security |
E-shutter |
| MANAGEABILITY |
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in |
| Included Upgrade |
3Y ADP -IPMAIN(ESS), 3Y Legion Ultimate Support -IPMAIN (ESS) |
| ACCESSORIES |
| Bundled Accessories |
None |
| CERTIFICATIONS |
| Green Certifications |
ENERGY STAR 8.0
ErP Lot 6/26
RoHS compliant |
| Other Certifications |
TÜV Rheinland Flicker Free
TÜV Rheinland High Gaming Performance
TÜV Rheinland Low Blue Light (Hardware Solution) |
