Description
Specifications
Appearance
-
Dimensions:
- Single-sided: 80 mm x 22 mm x 2.23 mm (3.15" x 0.87" x 0.09")
- Double-sided: 80 mm x 22 mm x 3.58 mm (3.15" x 0.87" x 0.14")
- Weight: 8 g (0.28 oz)
- Type: M.2 2280
Interface
- Bus Interface: NVMe PCIe Gen3 x4
Storage
- Flash Type: 3D NAND flash
- Capacity: 128 GB / 256 GB / 512 GB / 1 TB / 2 TB
Operating Environment
- Operating Temperature: 0°C (32°F) ~ 70°C (158°F)
- Operating Voltage: 3.3V±5%
Performance
-
Sequential Read/Write (CrystalDiskMark):
- 2 TB: Up to 2,500/1,700 MB/s
- 1 TB: Up to 1,700/1,400 MB/s
- 512 GB: Up to 1,700/1,400 MB/s
- 256 GB: Up to 1,600/1,100 MB/s
- 128 GB: Up to 1,500/550 MB/s
-
4K Random Read/Write (IOmeter):
- 2 TB: Up to 200,000/250,000 IOPS
- 1 TB: Up to 200,000/250,000 IOPS
- 512 GB: Up to 160,000/250,000 IOPS
- 256 GB: Up to 90,000/250,000 IOPS
- 128 GB: Up to 95,000/130,000 IOPS
-
Terabytes Written (TBW):
- 2 TB: 800 TBW
- 1 TB: 400 TBW
- 512 GB: 200 TBW
- 256 GB: 100 TBW
- 128 GB: 50 TBW
- Mean Time Between Failures (MTBF): 2,000,000 hour(s)
- Drive Writes Per Day (DWPD): 0.2 (5 yrs)
- Note: See below for additional notes
Warranty
- Certificate: CE / UKCA / FCC / BSMI / KC / RCM
- Warranty: Five-year Limited Warranty
- Warranty Policy: See website for more information
System Requirement
-
Operating System:
- Microsoft Windows 7 or later
- Linux Kernel 2.6.31 or later
- Note: See below for additional notes
Technology
- S.M.A.R.T.: Supported
- Advanced Garbage Collection: Supported
- RAID Engine: -
- LDPC Coding: Supported
- DRAM Cache: -
