Description
| Display | 32-bit PCI |
| Dimensions ( R x D x C ) | 5.2 x 4.8 x 0.9 in. (133 x 121 x 22mm) |
| Antenna Type | Omni Directional, Detachable (RP-SMA) |
| Antenna gain | 2x2dBi |
| WI-FI FEATURES | |
| Standard Wi-Fi | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Bands | 2.400-2.4835GHz |
| Signal speed | 11n: Up to 300Mbps(dynamic) |
| 11g: Up to 54Mbps(dynamic) | |
| 11b: Up to 11Mbps(dynamic) | |
| Reception Sensitivity | 270M: -68dBm@10% PER |
| 130M: -68dBm@10% PER | |
| 108M: -68dBm@10% PER | |
| 54M: -68dBm@10% PER | |
| 11M: -85dBm@8% PER | |
| 6M: -88dBm@10% PER | |
| 1M: -90dBm@8% PER | |
| Transmission capacity | <20dBm |
| Wi-Fi Mode | Ad-Hoc / Infrastructure mode |
| Wi-Fi Security | Support 64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Modulation Technology | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
| IS DIFFERENT | |
| Certificate | CE, FCC, RoHS |
| Products include | Wireless Adapter |
| Resource CD | |
| Quick Installation Guide | |
| System Requirements | Windows 7(32/64bits), Windows Vista(32/64bits), |
| Windows XP(32/64bits), Windows 2000 | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) |
| Storage Temperature: -40℃~70℃ (-40℉~158℉) | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90 % non-condensing | |
