| standards and protocols |
IEEE802.3i |
| IEEE802.3u |
| IEEE802.3ab |
| IEEE802.3x |
| interface |
8 10/100/1000Mbps RJ45 ports with auto-negotiation and auto-MDI/MDIX |
| Cable |
10BASE-T: Category 3 or higher UTP cable (100m or less) |
| 100BASE-TX: Category 5 or higher UTP cable (100m or less) |
| 1000BASE-T: Category 6 or higher UTP cable (100m or less) |
| number of fans |
0 |
| power supply |
100..240V/50..60Hz AC voltage |
| power consumption |
Maximum 3.32W (230V/50Hz) |
| Dimensions (W*D*H) |
294mm*180mm*44mm |
| Assembly |
Rack mountable |
| Maximum power consumption |
4.3W(220V/50Hz) |
| Maximum heat emission |
14.67BTU/hr |
| PERFORMANCE |
| switching capacity |
16Gbps |
| packet forwarding rate |
11.9Mpps |
| MAC address table |
8k |
| buffer storage |
2Mb |
| jumbo frames |
16kB |
| Green IT |
Green IT, saves up to 75% energy |
| transfer method |
Store and Forward |
| SOFTWARE FEATURES |
| Advanced features |
Green Technology |
| 802.3X Flow Control |
| 802.1p/DSCP QoS |
| IGMP Snooping |
| OTHERS |
| certification |
FCC |
| CE |
| RoHS |
| packaging content |
8-Port 10/100/1000Mbps Desktop Switch Power Cord Quick |
| Install Guide Rack Mount Kit Rubber Feet |
| |
| |
| system requirements |
Microsoft® Windows® 2000/XP/2003/Vista/2008/7/2012/8/10 |
| MacOS® |
| NetWare® |
| UNIX® |
| Linux |
| Vicinity |
Operating temperature: 0°C..40°C Storage |
| temperature: -40°C..70°C |
| Operating humidity: 10%..90% non-condensing Storage humidity |
| : 5%..90% non-condensing |
