| Standards and Protocols |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Interface |
24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
| Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m) |
| Fan Quantity |
Fanless |
| Physical Security Lock |
Yes |
| Power Supply |
External Power Adapter(Output: 9VDC/0.6A) |
| Power Consumption |
Maximum: 3.2W |
| Dimensions ( W x D x H ) |
11.6*7.1*1.7 in. (294*180*44 mm) |
| Mounting |
Rack Mountable |
| Max Power Consumption |
3.19W(220V/50Hz) |
| Max Heat Dissipation |
10.88BTU/h |
| PERFORMANCE |
| Switching Capacity |
4.8Gbps |
| Packet Forwarding Rate |
3.57Mpps |
| MAC Address Table |
8K |
| Buffer Memory |
2Mb |
| Green Technology |
Innovative energy-efficient technology saves power up to 75% |
| Transfer Method |
Store-and-Forward |
| OTHERS |
| Certification |
FCC, RoHS |
| Package Contents |
24-Port 10/100Mbps Desktop/Rackmount Switch |
| Power Cord |
| Installation Guide |
| Rackmount Kit |
| Rubber Feet |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) |
| Storage Temperature: -40℃~70℃ (-40℉~158℉) |
| Operating Humidity: 10%~90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
