Description
Standards | - IEEE 802.3, |
- IEEE 802.3u, | |
- IEEE 802.3ab, | |
- IEEE 802.3x | |
Interface | - 24*10/100/1000Mbps auto-negotiation RJ-45 Ports (Auto MDI/MDIX) |
Power Supply | - AC 100V~240V, 50/60Hz |
LED Indicators | - 1*Power, Link/Act (1~24), M1~M4 |
Dimensions(L x W x H) | - 17.3 x 7.1 x 1.7in. (440 x 180 x 44mm) |
MAC Address Learning | - Auto-learning, auto update |
MAC Address Table | - 8K |
Switching Capacity | - 48Gbps |
Network Media | - 10BASE-T: UTP Cat 3, 4, 5 cable |
- 100BASE-TX/1000BASE-T: UTP Cat 5, 5e or above cable | |
Four Working Modes | - M1: Flow Control OFF |
- M2: Flow Control ON | |
- M3: 23/24 Ports Aggregation based on MAC sources | |
- M4: 1-22 Port Isolation, 23~24 Port Uplink. | |
Frame Filtering | - 10Mbps: 14,880pps |
- 100Mbps: 148,800pps | |
- 1000Mbps: 1,488,000pps | |
Transfer Method | - Store-and-Forward |
Others | |
Package Contents | - SG24 Gigabit Switch |
- Quick Installation Guide | |
- Power Cord | |
- Brackets | |
- Rubber Feet | |
- Screws | |
Environment | - Operating Temperature: 0℃~50 ℃ (32 ℉~122℉) |
- Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) | |
- Operating Humidity: 5%~95% non-condensing | |
- Storage Humidity: 5%~95% non-condensing |
