| Processor |
Intel Core i3-1115G4 (2C / 4T, 3.0 / 4.1GHz, 6MB)
|
| Graphics |
Integrated Intel UHD Graphics
|
| Chipset |
Intel SoC Platform
|
| Memory |
1x 8GB SO-DIMM DDR4-3200
|
| Memory Slots |
One DDR4 SO-DIMM slot
|
| Max Memory |
Up to 32GB DDR4-3200
|
| Storage |
256GB SSD M.2 2242 PCIe 3.0x4 NVMe
|
| Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB
|
| Storage Slot |
Two M.2 slots • One M.2 2242 PCIe 3.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot
|
| Card Reader |
No card reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby Audio, audio by HARMAN
|
| Camera |
HD 720p with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 45Wh
|
| Max Battery Life |
MobileMark 2014: 11.9 hr MobileMark 2018: 8.7 hr
|
| Power Adapter |
65W USB-C (3-pin)
|
| DESIGN |
| Display |
14" FHD (1920x1080) TN 220nits Anti-glare, 45% NTSC
|
| Touchscreen |
None
|
| Keyboard |
Backlit, English
|
| Case Color |
Black
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Dimensions (WxDxH) |
324 x 220 x 18.9 mm (12.76 x 8.66 x 0.74 inches)
|
| Weight |
Starting at 1.59 kg (3.51 lbs)
|
| SOFTWARE |
| Operating System |
Windows 10 Pro 64, English
|
|
|
| CONNECTIVITY |
| Ethernet |
100/1000M
|
| WLAN + Bluetooth |
Intel 9560 11ac, 2x2 + BT5.1
|
| WWAN |
None
|
| SIM Card |
None
|
| NFC |
None
|
| Standard Ports |
- 1x USB 2.0
- 1x USB 3.2 Gen 1 (Always On)
- 1x Thunderbolt 4 / USB 4 40Gbps (support data transfer, Power Delivery 3.0, and DisplayPort 1.4)
- 1x HDMI 1.4b
- 1x Ethernet (RJ-45)
- 1x Headphone / microphone combo jack (3.5mm)
|
| Docking |
|
| Monitor Cable |
None
|
| SECURITY & PRIVACY |
| Smart Card Reader |
None
|
| Security Chip |
Discrete TPM 2.0
|
| Fingerprint Reader |
Touch Style
|
| Physical Locks |
Kensington Security Slot, 3 x 7 mm
|
| Other Security |
Camera privacy shutter
|
| MANAGEABILITY |
| System Management |
Non-vPro
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y Courier/Carry-in upgrade from 1Y Courier/Carry-in (5WS0A23813)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications |
- EPEAT Gold
- ENERGY STAR 8.0
- ErP Lot 3
- TCO Certified
- RoHS compliant
|
| Other Certifications |
TÜV Rheinland Low Blue Light
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
