Quick Specs: |
• Processor - Intel Core i5-13420H • Graphics - Integrated Intel UHD Graphics • Memory - 16GB Soldered DDR4-3200 • Storage - 512GB SSD M.2 2242 PCIe 4.0x4 NVMe • Resolution - (1920x1200) IPS • Panel size - 14" WUXGA • Battery - Integrated 47Wh |
Full Specs:
Processor: Intel® Core i5-13420H, 8C (4P + 4E) / 12T, P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB
Graphics: Integrated Intel® UHD Graphics
Chipset: Intel® SoC Platform
Memory: 16GB Soldered DDR4-3200
Memory Slots One memory soldered to system board, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory Up to 40GB
Storage: 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Support Up to two drives, 2x M.2 SSD M.2 2242 SSD up to 1TB
Storage Slot Two M.2 slots One M.2 2242 PCIe® 3.0 x4 slot ? One M.2 2242 PCIe 4.0 x4 slot
Card Reader No card reader
Optical None
Audio Chip High Definition (HD) Audio, Synaptic® CX11880 codec
Speakers: Stereo speakers, 2W x2, Dolby Atmos®
Camera HD 720p with Privacy Shutter
Microphone 2x, Array
Battery Integrated 47Wh
Max Battery Life -
Power Adapter 65W USB-C® (3-pin)
DESIGN
Display: 14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC
Touchscreen: None
Keyboard: Backlit, English
Case Color: Graphite Black
Surface Treatment -
Case Material: Aluminum (Top), PC-ABS (Bottom)
Dimensions (WxDxH) 313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches)
Weight Starting at 1.41 kg (3.11 lbs)
SOFTWARE
Operating System: Windows® 11 Pro, English
Bundled Software: None
CONNECTIVITY
Ethernet 100/1000M (RJ-45)
WLAN + Bluetooth: Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.1
WWAN None
SIM Card: None
NFC: None
Standard Ports
1x USB 2.0
1x USB 3.2 Gen 1 (Always On)
1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort? 1.4)
1x Thunderbolt? 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort? 1.4)
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Docking Various docking solutions supported via Thunderbolt? or USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® E14 Gen 5 (Intel®)
Monitor Cable -
SECURITY & PRIVACY
Smart Card Reader: None
RFID Reader
Security Chip: Discrete TPM 2.0 Enabled
Fingerprint Reader: Touch Style, Integrated in Power Button
Physical Locks Kensington® Nano Security Slot?, 2.5 x 6 mm
Other Security: Camera privacy shutter
