| Processor |
AMD Ryzen™ 9 7940HS (8C / 16T, 4.0 / 5.2GHz, 8MB L2 / 16MB L3)
|
| Graphics |
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 105W
|
| Chipset |
AMD SoC Platform
|
| Memory |
16GB Soldered LPDDR5x-6400
|
| Memory Slots |
Memory soldered to systemboard, no slots
|
| Max Memory |
16GB soldered memory, not upgradable
|
| Storage |
1TB SSD M.2 2280 PCIe® 4.0x4 NVMe®
|
| Storage Support
|
Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 1TB
|
| Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots
|
| Card Reader |
4-in-1 Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, Nahimic Audio
|
| Camera |
FHD 1080p with E-shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 73.6Wh
|
| Power Adapter |
170W Slim Tip (3-pin)
|
| Special Features |
Legion Coldfront 5.0 cooling system
|
| DESIGN |
| Display |
14.5 WQXGA+ (2880x1800) OLED 400nits Glossy, 100% DCI-P3, 120Hz, DisplayHDR™ True Black 500, Dolby® Vision™
|
| Touchscreen |
None
|
| Color Calibration |
Factory Color Calibration
|
| Keyboard |
White Backlit, English
|
| Case Color |
Storm Grey
|
| Surface Treatment |
Anodizing
|
| Case Material |
Aluminium (Top), Aluminium (Bottom)
|
| Dimensions (WxDxH)
|
327.49 x 250.62 x 17.9-21.29 mm (12.89 x 9.87 x 0.70-0.84 inches)
|
| Weight
|
Less than 1.75 kg (3.86 lbs)
|
| SOFTWARE |
| Operating System |
Windows® 11 Home Single Language, English
|
| Bundled Software |
Office Trial
|
| CONNECTIVITY |
| Ethernet |
No Onboard Ethernet
|
| WLAN + Bluetooth
|
Wi-Fi® 6E, 11ax 2x2 + BT5.1
|
| Standard Ports |
- 1x USB 3.2 Gen 2
- 1x USB 3.2 Gen 2 (Always On)
- 1x USB-C® 3.2 Gen 2 (support data transfer and DisplayPort™ 1.4)
- 1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 140W and DisplayPort™ 1.4)
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Card reader
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Power connector
|
| Security Chip |
Firmware TPM 2.0 Enabled
|
| Fingerprint Reader |
Touch Style, Integrated in Power Button
|
| Other Security |
E-shutter
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y Legion Ultimate Support -IPMAIN (ESS)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications
|
- ENERGY STAR® 8.0
- EPEAT™ Silver Registered
- ErP Lot 6
- ErP Lot 26
- RoHS compliant
|
| Other Certifications |
TÜV Rheinland® Low Blue Light (Hardware Solution)
|
