| Processor |
Intel® Core™ i7-1255U, 10C (2P + 8E) / 12T, P-core 1.7 / 4.7GHz, E-core 1.2 / 3.5GHz, 12MB
|
| Graphics |
Integrated Intel® Iris® Xe Graphics Functions as UHD Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
8GB Soldered DDR4-3200
|
| Memory Slots |
One memory soldered to system board, one DDR4 SO-DIMM slot, dual-channel capable
|
| Max Memory |
Up to 16GB (8GB soldered + 8GB SO-DIMM) DDR4-3200 offering
|
| Storage |
512GB SSD M.2 2280 PCIe® 3.0x4 NVMe®
|
| Storage Support |
Models with 45Wh battery: one drive, 1x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
|
| Storage Slot |
Models with 45Wh battery: one M.2 slot • One M.2 2280 PCIe® 4.0 x4 slot
|
| Card Reader |
4-in-1 Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio
|
| Speakers |
Stereo speakers, 1.5W x2, Dolby® Audio™
|
| Camera |
HD 720p with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 45Wh
|
| Max Battery Life |
Models with 45Wh battery: MobileMark® 2018: 6 hr Local video (1080p) playback@150nits: 10 hr
|
| Power Adapter |
65W Round Tip (3-pin)
|
| DESIGN |
| Display |
14" FHD (1920x1080) IPS 300nits Anti-glare
|
| Touchscreen |
None
|
| Keyboard |
Backlit, English
|
| Case Color |
Abyss Blue
|
| Surface Treatment |
IMR (In-Mold Decoration by Roller)
|
| Case Material |
PC-ABS (Top), PC-ABS (Bottom)
|
| Dimensions (WxDxH) |
324.2 x 215.7 x 19.9 mm (12.76 x 8.49 x 0.78 inches)
|
| Weight |
Starting at 1.43 kg (3.15 lbs)
|
| SOFTWARE |
| Operating System |
Windows® 11 Home Single Language, English
|
| Bundled Software |
Office Home & Student 2021
|
| CONNECTIVITY |
| Ethernet |
No Onboard Ethernet
|
| WLAN + Bluetooth® |
Wi-Fi® 6, 11ax 2x2 + BT5.1
|
| Standard Ports |
- 1x USB 2.0
- 1x USB 3.2 Gen 1
- 1x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.2)
- 1x HDMI® 1.4b
- 1x Card reader
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Power connector
|
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0
|
| Fingerprint Reader |
Touch Style, Integrated in Power Button
|
| Other Security |
Camera privacy shutter
|
