| PERFORMANCE |
| Processor |
Intel® Core™ Ultra 7 155H, 16C (6P + 8E + 2LPE) / 22T, Max Turbo up to 4.8GHz, 24MB
|
| AI PC Category
|
AI PC
|
| NPU |
Integrated Intel® AI Boost, up to 11 TOPS
|
| Graphics |
NVIDIA® GeForce RTX™ 4050 6GB GDDR6
|
| Chipset |
Intel® SoC Platform
|
| Memory |
32GB Soldered LPDDR5x-7467
|
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
| Max Memory |
32GB soldered memory, not upgradable
|
| Storage |
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
|
| Max Storage Support
|
Models with discrete graphics: one drive, 1x M.2 SSD • M.2 2242 SSD up to 1TB
|
| Storage Slot |
Models with discrete graphics: one M.2 2242 PCIe® 4.0 x4 slot
|
| Card Reader |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3306 codec
|
| Speakers |
4 stereo speakers, 2W x2 (woofers), 2W x2 (tweeters), optimized with Dolby Atmos®, Amplifier (AMP)
|
| Camera |
FHD 1080p + IR with E-shutter
|
| Microphone |
4x, Array
|
| Battery
|
73Wh
|
| Power Adapter |
140W USB-C® Slim (3-pin)
|
| DESIGN |
| Display |
14.5" 2.8K WQXGA+ (2880x1800) OLED 400nits Glossy, 100% P3, 120Hz, Eyesafe®, Dolby Vision®, DisplayHDR™ True Black 500, Glass, X-Rite®
|
| Touchscreen |
None
|
| Color Calibration |
Factory Color Calibration
|
| Keyboard |
Backlit, English
|
| Touchpad |
Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 80 x 135 mm (3.15 x 5.31 inches)
|
| Case Color |
Tidal Teal
|
| Surface Treatment |
Aluminium Stamping (Anodized with Sandblasting)
|
| Case Material |
Aluminium (Top), Aluminium (Bottom)
|
| Pen |
Pen Not Supported
|
| Dimensions (WxDxH)
|
325.5 x 226.49 x 16.6 mm (12.81 x 8.92 x 0.65 inches)
|
| Weight
|
Starting at 1.59 kg (3.50 lbs)
|
| SOFTWARE |
| Operating System |
Windows® 11 Home Single Language, English
|
| Bundled Software |
Office Home & Student 2021
|
| CONNECTIVITY |
| WLAN + Bluetooth
|
Wi-Fi® 6E, 802.11ax 2x2 + BT5.3
|
| WWAN |
Non-WWAN
|
| Ethernet |
No Onboard Ethernet
|
| Standard Ports |
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0 and DisplayPort™ 1.4
- 1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
|
| Docking |
Various docking solutions are supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for Yoga® Pro 7 14IMH9
|
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0
|
| Fingerprint Reader |
None
|
| Other Security |
- E-shutter
- IR camera for Windows® Hello (facial recognition)
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y ADP - IPPREM (ESS), 3Y Premium Care -IPPREM (ESS)
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| CERTIFICATIONS |
| Green Certifications
|
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
|
| Other Certifications |
- Eyesafe® Certified 2.0
- Intel® Evo™ Platform
- TÜV Rheinland® Low Blue Light (Hardware Solution)
|
| Mil-Spec Test |
MIL-STD-810H military test passed (21 test items)
|
