Description
Full Specs:
| Camera | |
| Image Sensor | 1/4" Color CMOS |
| Horizontal Resolution | N/A |
| Lens | 4.6mm, F1.9 |
| Iris Operation | Fixed |
| Pan & Tilt | Manually adjustable |
| Minimum Illumination | 1 Lux at F1.9 |
| IR Illumination | No |
| Analog Video Output | No |
| Built-In Microphone | No |
| Audio Input | No |
| Audio Output | No |
| Controls | Electronic Shutter (1/60-1/15,000 sec) |
| Motion Detection | Yes |
| Alarm I/O | No |
| Control Connectors | N/A |
| Network | |
| Compression Format | MJPEG (JPEG for still images) |
| Picture Size | 640 x 480, 320 x 240, 160 x 120 |
| Frame Rate | 15 FPS at 640 x 480 30 FPS at 320 x 24010 FPS at 160 x 120 |
| Supported Protocols | IPv4, ARP, TCP, UDP, ICMP, DHCP Client, NTP Client, DDNS Client, DNS Client, SMTP Client, LLTD, FTP Client, HTTP Server, PPPoE |
| Card Slot | No |
| Web Browser Access | Viewing, recording, playback |
| Simultaneous Client Access | Yes |
| Multiple Camera Views | Up to 32 |
| Network Interface | RJ-45 (10/100 Ethernet) |
| System Requirements | Windows XP SP2, Vista 1.3 GHz Processor 128MB Memory IE 6.0 or later Wired network |
| General | |
| Power Requirements | 5VDC (includes power adapter) |
| Power Consumption | 2.5A |
| Operating Temperature | 32 - 104°F (0 - 40°C) |
| Dimensions | 2.8 x 1.5 x 4.3" (71 x 38 x 109mm) |
| Weight | 0.5 lbs (227g) |
