Description
Specifications:
|
Camera |
|
|
Image Sensor |
1/2.8" CMOS |
|
Max Resolution |
1920 (H) × 1080 (V) |
|
ROM |
16 MB |
|
RAM |
64 MB |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
|
Min. Illumination |
0.025 lux@F2.0 (Color, 30 IRE); 0.0025 lux@F2.0 (B/W, 30 IRE); 0 lux (Illuminator on) |
|
S/N Ratio |
> 56 dB |
|
Illumination Distance |
30 m (98.43 ft) |
|
Illuminator On/Off Control |
Auto; Manual |
|
Illuminator Number |
1 (IR LED) |
|
Pan/Tilt/Rotation Range |
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
|
Lens |
|
|
Lens Type |
Fixed-focal |
|
Lens Mount |
M12 |
|
Focal Length |
2.8 mm; 3.6 mm |
|
Max Aperture |
F2.0 |
|
Field of View |
2.8 mm: H: 100°; V: 53°; D: 120° |
|
Iris Control |
Fixed |
|
Close Focus Distance |
2.8 mm: 0.6 m (1.97 ft); 3.6 mm: 1.0 m (3.28 ft) |
|
DORI Distance |
2.8 mm: Detect: 46.9 m; Observe: 18.8 m; Recognize: 9.4 m; Identify: 4.7 m |
|
Video |
|
|
Video Compression |
H.264B; H.264; H.264H; H.265 |
|
Smart Codec |
Smart H.265+; Smart H.264+ |
|
Video Frame Rate |
Mainstream: 1920 × 1080 (1–25/30 fps); Substream: 640 × 480 (1–25/30 fps) |
|
Stream Capability |
2 streams |
|
Resolution |
1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720) |
|
Bit Rate Control |
CBR/VBR |
|
Video Bit Rate |
H.264: 24 kbps–4096 kbps; H.265: 9 kbps–4096 kbps |
|
Day/Night |
Auto (ICR)/Color/B/W |
|
BLC |
Yes |
|
WDR |
DWDR |
|
White Balance |
Auto; natural; streetlamp; outdoor; manual; regional custom |
|
Gain Control |
Auto |
|
Noise Reduction |
3D NR |
|
Motion Detection |
1024 kbps (1080p) |
|
Smart Illumination |
Yes |
|
Image Rotation |
0°/180° |
|
Mirror |
Yes |
|
Audio |
|
|
Built-in MIC |
Yes |
|
Built-in Speaker |
Yes |
|
Audio Compression |
G.711a; G.711Mu |
|
Alarm |
|
|
Alarm Events |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; intensity change |
|
Network |
|
|
Network Port |
RJ-45 (10/100 Base-T) |
|
Wi-Fi |
IEEE802.11b/g/n 2.4–2.4835 GHz; 2.4 G |
|
Wireless Range |
Up to 150 m |
|
SDK and API |
Yes |
|
Cyber Security |
Video/configuration encryption; Digest; WSSE; account lockout; logs; X.509 certification; HTTPS; trusted boot/execution/upgrade |
|
Network Protocol |
IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP |
|
Interoperability |
ONVIF (Profile S/Profile T); CGI; P2P |
|
User/Host |
6 (Total bandwidth: 36 M) |
|
