Description
The Tenda CP3 v3 is a smart indoor pan-and-tilt security camera designed to deliver reliable home monitoring with clear 3MP 2K video, intelligent human detection, and smooth 360° coverage. Equipped with a progressive scan CMOS sensor, H.265 video compression, and infrared night vision up to 10 meters, it captures detailed footage day and night while optimizing storage and bandwidth efficiency. Its 355° horizontal and 55° vertical pan-and-tilt range, human tracking, panoramic patrol mode, and customizable preset positions provide flexible monitoring for homes, apartments, nurseries, and small offices. The camera also features two-way audio, privacy masking, customizable alarm audio, local microSD storage support up to 256GB, and Wi-Fi 6 connectivity for stable wireless performance. With ONVIF and RTSP support, mobile and PC remote access through the TDSEE app, and flexible desktop or ceiling mounting options, the Tenda CP3 v3 offers a practical and easy-to-use solution for everyday indoor surveillance and smart home security.
|
Camera |
|
|
Image Sensor |
1/3 Progressive Scan CMOS sensor |
|
Day and Night |
ICR type |
|
Lens |
|
|
Focal Length |
4mm |
|
Aperture |
F2.0 |
|
FOV |
Horizontal FOV: 84°, Vertical FOV: 53.1°, Diagonal FOV: 91.1° |
|
Illuminator |
|
|
Supplementary Light |
4 IR Lights |
|
Supplementary Light Distance |
Up to 10 m/30 ft (depending on environment) |
|
IR Wavelength |
850nm |
|
Night Vision Mode |
Black & White Mode |
|
Video |
|
|
Video Encoding Format |
H.265 |
|
Main Stream Resolution |
2304 ×1296 |
|
Sub Stream Resolution |
640 x 360 |
|
Frame Rate |
1-20fps, Default 20fps |
|
Bit Rate |
128kbps -- 4096kbps |
|
Bit Rate Control |
VBR |
|
Audio |
|
|
Audio Encoding Format |
G.711A, G.711U, AAC |
|
Audio Sampling Rate |
8 kHz |
|
Audio Communication |
Two-way Audio |
|
Image |
|
|
Image Enhancement |
DWDR, 3D DNR |
|
Privacy Mask: |
4 Areas |
|
Network |
|
|
ONVIF |
Support |
|
Protocols: |
• TCP/IP • UDP • ICMP • HTTP • HTTPS • DHCP • DNS • DDNS • RTP • RTSP • RTCP • NTP • ARP |
|
Client |
TDSEE (mobile phone), TDSEE STUDIO (PC) |
|
Pan & Tilt |
|
|
Pan Movement Range |
0°--355° |
|
Tilt Movement Range |
-15°--55° |
|
Preset |
6 |
|
Patrol |
Panoramic Patrol, Preset Patrol |
|
Wi-Fi |
|
|
Antenna |
Internal antenna |
|
Wireless Standard |
IEEE 802.11 b/g/n/ax |
|
Transmission Rate |
Up to 287Mbps |
|
Channel Width |
20/40 MHz |
|
Modulation |
DSSS/OFDM/OFDMA |
|
Frequency Band |
2.4GHz: 2412MHz-2472MHz(CH1-CH13) |
|
Transmit Power |
2.4GHz: <0.1W(EIRP) |
|
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
|
Alarm |
|
|
Smart Detection |
Motion Detection, Human Detection |
|
Smart Linkage |
Human Tracking |
|
DIY Audio |
3 Customized Audios |
|
Interface |
|
|
Audio Input |
Built-in MIC, adjustable microphone volume |
|
Audio Output: |
Built-in Speaker, 68 dBA (Alarm sound at 1 meter), adjustable sound level |
|
Storage |
Supports up to 256 GB Micro SD card |
|
Reset Button |
Support |
|
LED Indicator: |
Dual Color(red & blue) |
|
General |
|
|
Power |
5 V 1A, Type-C Power Plug |
|
Material |
Plastic |
|
Product Dimension |
76.7mm x76.7mm x110.4mm(3'' × 3'' × 4.3'') |
|
Package Dimension |
84mm x 84mm x 165mm (3.3'' × 3.3'' × 6.5'') |
|
Product Weight |
158g(0.34lb) |
|
With Package Weight |
331g(0.73lb) |
|
Installation Method |
Desktop, Ceiling Mounting |
|
Certification |
CE, RoHS, FCC, RCM, UKCA |
|
Temperature: |
• Operating Temperature: -30°C ~ 60°C (-22°F ~ 140°F) • Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) |
|
Humidity: |
• Operating Humidity: 10% ~ 95% RH (non-condensing) • Storage Humidity: 3% ~ 95% RH (non-condensing) |
|
Package Contents |
•Camera •Power Adapter (cord length: 1.5m) •Installation Template •Mounting Bracket •Mounting Accessories Kit •Quick Installation Guide |
