Description
Full Specifications
| Category | Details |
|---|---|
| Print Head / Consumables | |
| Number of Nozzles | Total: 5,120 nozzles |
| Ink Cartridges (Type/Colours) | PG-750 (Pigment Ink / Black) |
| CLI-751 (Dye-Based Ink / Cyan, Magenta, Yellow, Black) | |
| Optional Cartridges | PGI-755XXL (Pigment Ink / Black) |
| PGI-750XL PGBK (Pigment Ink / Black) | |
| CLI-751XL (Dye-Based Ink / Cyan, Magenta, Yellow, Black) | |
| Maximum Print Resolution | 9,600 (horizontal) × 2,400 (vertical) dpi |
| Print Speed (Approx.) | |
| Document (ESAT/Simplex) | 14.5 ipm (mono) / 10.4 ipm (colour) |
| Photo (11 × 14") (PP-201) | 120 sec |
| Photo (4 × 6") (PP-201, Borderless) | 36 sec |
| Print Width | Up to 322.2 mm (12.7") |
| Borderless: Up to 329 mm (13") | |
| Recommended Printing Area | |
| Top Margin | 40.7 mm |
| Bottom Margin | 37.4 mm |
| Paper Handling | |
| Print Margin | |
| Borderless Printing | Top/Bottom/Left/Right: 0 mm |
| Bordered Printing | LTR, LGL: Top: 3 mm, Bottom: 5 mm, Left: 6.4 mm, Right: 6.3 mm |
| Others: Top: 3 mm, Bottom: 5 mm, Left/Right: 3.4 mm | |
| Supported Media (Rear Tray) | Plain Paper (64 - 105 g/m²) |
| High Resolution Paper (HR-101N) | |
| Photo Paper Pro Platinum (PT-101) | |
| Photo Paper Pro Luster (LU-101) | |
| Photo Paper Plus Glossy II (PP-201) | |
| Photo Paper Plus Semi-Gloss (SG-201) | |
| Matte Photo Paper (MP-101) | |
| Envelope | |
| Paper Size (Rear Tray) | A3+, A3, A4, A5, B4, B5, LTR, LGL, LDR |
| Envelope (COM10, DL) | |
| 4 × 6", 5 × 7", 8 × 10", 10 × 12" | |
| Custom Size | Width: 55 - 329 mm |
| Length: 91 - 676 mm | |
| (F4 possible via custom size settings) | |
| Borderless Printing | A3+, A3, A4, LTR, LDR, 4 × 6", 5 × 7", 8 × 10", 10 × 12" |
| Maximum Capacity (Rear Tray) | |
| Plain Paper (64 g/m²) | A3, A4, A5, B4, B5, LTR, LGL, LDR: 150 sheets |
| High Resolution Paper | (HR-101N) A3+/A3/A4: 20/50/80 sheets |
| Photo Paper Pro Platinum | (PT-101) A3+/A3/A4/4 × 6": 1/10/10/20 sheets |
| Photo Paper Pro Luster | (LU-101) A3+/A3/A4: 1/10/10 sheets |
| Photo Paper Plus Glossy II | (PP-201) A3+/A3/A4/4 × 6": 1/10/10/20 sheets |
| Photo Paper Plus Semi-Gloss | (SG-201) A3+/A3/A4/8 × 10/4 × 6": 1/10/10/10/20 sheets |
| Matte Photo Paper | (MP-101) A3/A4/4 × 6": 10/10/20 sheets |
| Envelope | (COM10, DL): 10 sheets |
| Paper Weight (Front Tray) | Plain Paper: 64 - 105 g/m² |
| Canon Paper: Approx. 300 g/m² (Max.) | |
| (Photo Paper Pro Platinum, PT-101) | |
| Printing Solutions | Canon Printing Apps |
| Other Software | Easy-PhotoPrint Editor, Easy Layout Editor |
| System Requirements | |
| OS Compatibility | Windows 8 / 7 / XP / Vista |
| macOS X 10.6.8 or later | |
| General Specifications | |
| Interface | USB 2.0 |
| Operating Environment | |
| Temperature | 5 - 35°C |
| Humidity | 10 - 90% RH (no dew condensation) |
| Recommended Environment | |
| Temperature | 15 - 30°C |
| Humidity | 10 - 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 - 40°C |
| Humidity | 5 - 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise | Photo (4 × 6"): 44.5 dB(A) |
| Power Requirements | AC 100 - 240 V, 50/60 Hz |
| Power Consumption (Approx.) | |
| OFF | 0.2 W |
| Standby | 0.8 W |
| Operation | 21 W |
| Dimensions (W × D × H) | Factory Configuration: 584 × 310 × 159 mm |
| Weight | 8.1 kg |
| Page Yield (Plain Paper) | |
| A4 Colour Documents | PGI-750 PGBK: 300 sheets |
| CLI-751 BK: 1645 sheets | |
| CLI-751 C, M, Y: 334 sheets | |
| Optional Cartridges | |
| PGI-750XL PGBK | 500 sheets |
| PGI-755XXL PGBK | 800 sheets |
| CLI-751XL BK | 5000 sheets |
| CLI-751XL C, M, Y | 690 sheets |
| Page Yield (Photo Paper) | |
| 4 × 6" Photos | PGI-750 PGBK: 2390 photos |
| CLI-751 BK: 384 photos | |
| CLI-751 C, M, Y: 128 photos | |
| Optional Cartridges | |
| PGI-750XL PGBK | 4720 photos |
| PGI-755XXL PGBK | 7685 photos |
| CLI-751XL BK | 845 photos |
| CLI-751XL C, M, Y | 305 photos |
