Description
Demo Unit
| Quick Specs: | • Processor - Intel® Core™ i5-1240P • Graphics - Intel® Iris Xe Graphics • Memory - 16GB LPDDR5 on board • Storage - 512GB M.2 NVMe™ PCIe® 4.0 Performance SSD • Resolution - 2.8K (2880 x 1800) OLED 16:10 aspect ratio • Panel size - 14.0-inch • Battery - 75WHrs, 2S2P, 4-cell Li-ion |
||
Full Specs:
| Part No | 90NB0WC1-M00EW0 |
| Model Name | UX3402ZA-KM062WS |
| EAN Code | 4711081796114 |
| UPC Code | 195553796118 |
| Operating System | Windows 11 Home - ASUS recommends Windows 11 Pro for business |
| LCD cover-material | Aluminum |
| LCD cover-color | Ponder Blue |
| Top case-material | Aluminum |
| Top case-color | Ponder Blue |
| Bottom case-material | Aluminum |
| Bottom case-color | Ponder Blue |
| Military grade | US MIL-STD 810H military-grade standard |
| Touch Panel | Non-touch screen |
| Panel Size | 14.0-inch |
| Resolution | 2.8K (2880 x 1800) OLED 16:10 aspect ratio |
| Response time | 0.2ms response time |
| Refresh rate | 90Hz refresh rate |
| Brightness | 400nits |
| Peak Brightness | 600nits HDR peak brightness |
| Color gamut | 100% DCI-P3 color gamut |
| Gamut mapping | Yes |
| Contrast ratio | 1,000,000:1 |
| VESA CERTIFIED Display HDR | VESA CERTIFIED Display HDR True Black 600 |
| Color depth | 1.07 billion colors |
| Pantone | PANTONE Validated |
| Glare | Glossy display |
| Low blue light | 70% less harmful blue light |
| SGS Eye Care Display | SGS Eye Care Display |
| Screen-to-body ratio | 90 ％ |
| Intel Athena Program | Intel® Evo™ Platform |
| Processor | Intel® Core™ i5-1240P Processor 1.7 GHz (12M Cache, up to 4.4 GHz, 4P+8E cores) |
| Chipset | N/A |
| Discrete/Share | Share |
| Intergrated GPU | Intel® Iris Xe Graphics |
| Disclaimer for Intel Iris Xe | *Intel Iris Xᵉ Graphics is only available in models with Intel® Core™ i5/i7/i9 processors and dual-channel memory. |
| VRAM | N/A |
| Expansion Slot(includes used) | N/A |
| On board memory | 16GB LPDDR5 on board |
| Total System Memory | LPDDR5 16GB |
| Disclaimer for memory | *Supports dual-channel memory. |
| Storage | 512GB M.2 NVMe™ PCIe® 4.0 Performance SSD |
| Front-facing camera | 720p HD camera |
| Wireless | Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5 |
| NumberPad | Support NumberPad |
| ScreenPad? | N/A |
| FingerPrint | FingerPrint |
| I/O ports | 1x USB 3.2 Gen 2 Type-A 2x Thunderbolt™ 4 supports display / power delivery 1x HDMI 2.1 TMDS 1x 3.5mm Combo Audio Jack Micro SD card reader |
| Audio | Smart Amp Technology Built-in speaker Built-in microphone harman/kardon (Premium) |
| Voice control | with Cortana and Alexa voice-recognition support |
| AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100-240V AC 50/60GHz universal |
| Battery | 75WHrs, 2S2P, 4-cell Li-ion |
| Replaceable Battery | No |
| Keyboard type | Backlit Chiclet Keyboard |
| Dimension (WxHxD) | 31.36 x 22.06 x 1.69 ~ 1.69 cm |
| Weight (with Battery) | 1.39 kg |
| Weight (without Battery) | 1.10 kg |
| Security | Fingerprint sensor integrated with Power Key McAfee® LiveSafe™ Trusted Platform Module (TPM) |
| MyASUS feature | System diagnosis Battery health charging Fan Profile Splendid Tru2Life Function key lock WiFi SmartConnect Link to MyASUS TaskFirst Live update AI Noise Canceling |
| Built-in Apps | MyASUS ScreenXpert GlideX |
| Adobe Creative Cloud Hard Bundle | Three-Month Membership of Adobe Creative Cloud All Apps, Individual. The redemption duration from September 15, 2021 to November 15, 2022. |
| Included in the Box | Sleeve |
| Reparability Index (for France) | 7.6 |
