Description
| Quick Specs: | • Processor - AMD Ryzen™ 5 7530U • Graphics - AMD Radeon™ Graphics • Memory - 8GB DDR4 on board • Storage - 512GB M.2 NVMe™ PCIe® 3.0 SSD • Resolution - FHD (1920 x 1080) • Panel size - 15.6-inch • Battery - 50WHrs, 3S1P, 3-cell Li-ion |
||
Full Specs:
| Part No | 90NB1181-M005K0 |
| Model Name | M3504YA-L1152WS |
| EAN Code | 4711387181973 |
| UPC Code | 197105181977 |
| Marketing Name | ASUS Vivobook 15X OLED |
| Operating System | Windows 11 Home - ASUS recommends Windows 11 Pro for business |
| Office | Microsoft Office Home & Student 2021 |
| LCD cover-material | Aluminum |
| LCD cover-color | Indie Black |
| Top case-material | Plastic |
| Top case-color | Indie Black |
| Keyboard color | Black |
| Bottom case-material | Plastic |
| Bottom case-color | Indie Black |
| Military grade | US MIL-STD 810H military-grade standard |
| Touch Panel | Non-touch screen |
| Panel Size | 15.6-inch |
| Resolution | FHD (1920 x 1080) OLED 16:9 aspect ratio |
| Response time | 0.2ms response time |
| Refresh rate | 60Hz refresh rate |
| Peak Brightness | 600nits HDR peak brightness |
| Color gamut | 100% DCI-P3 color gamut |
| Gamut mapping | Yes |
| Contrast ratio | 1,000,000:1 |
| VESA CERTIFIED Display HDR | VESA CERTIFIED Display HDR True Black 600 |
| Color depth | 1.07 billion colors |
| Pantone | PANTONE Validated |
| Glare | Glossy display |
| Low blue light | 70% less harmful blue light |
| T?V Rheinland-certified | TÜV Rheinland-certified |
| Screen-to-body ratio | 85 ％ |
| Processor | AMD Ryzen™ 5 7530U Processor 2.0GHz (19MB Cache, up to 4.5 GHz, 6 cores, 12 Threads) |
| Chipset | N/A |
| Discrete/Share | Share |
| Intergrated GPU | AMD Radeon™ Graphics |
| VRAM | N/A |
| How to upgrade memory | Upgradable; Need to remove bottom/top case |
| Expansion Slot(includes used) | 1x DDR4 SO-DIMM slot 1x M.2 2280 PCIe 3.0x4 |
| On board memory | 8GB DDR4 on board |
| Total System Memory | DDR4 8GB |
| Storage | 512GB M.2 NVMe™ PCIe® 3.0 SSD |
| Front-facing camera | 720p HD camera ; With privacy shutter |
| Wireless | Wi-Fi 5(802.11ac) (Dual band) 1*1 + Bluetooth® 5.1 Wireless Card (*Bluetooth® version may change with OS version different.) |
| Touchpad | Precision touchpad |
| FingerPrint | FingerPrint |
| I/O ports | 1x USB 2.0 Type-A 1x USB 3.2 Gen 1 Type-C support power delivery 2x USB 3.2 Gen 1 Type-A 1x HDMI 1.4 1x 3.5mm Combo Audio Jack 1x DC-in |
| Audio | SonicMaster Built-in speaker Built-in array microphone |
| Voice control | with Cortana voice-recognition support |
| AC Adapter | ø4.5, 65W AC Adapter, Output: 19V DC, 3.42A, 65W, Input: 100~240V AC 50/60Hz universal |
| Battery | 50WHrs, 3S1P, 3-cell Li-ion |
| Replaceable Battery | No |
| Keyboard type | Backlit Chiclet Keyboard with Num-key |
| Dimension (WxHxD) | 35.97 x 23.25 x 1.79 ~ 1.79 cm (14.16" x 9.15" x 0.70" ~ 0.70") |
| Weight (with Battery) | 1.60 kg (3.53 lbs) |
| Weight (without Battery) | 1.60 kg (3.53 lbs) |
| Antivirus | McAfee® 30 days free trial |
| Security | McAfee® 30 days free trial Fingerprint sensor integrated with Touchpad McAfee® BIOS Booting User Password Protection BIOS setup user password Trusted Platform Module (Firmware TPM) |
| MyASUS feature | System diagnosis Battery health charging Fan Profile Splendid Function key lock WiFi SmartConnect Link to MyASUS TaskFirst Live update ASUS OLED Care AI Noise Canceling |
| Built-in Apps | MyASUS ScreenXpert GlideX |
| Adobe Creative Cloud Hard Bundle | One-Month Membership of Adobe Creative Cloud All Apps, Individual. The redemption duration from September 15, 2021 to August 31, 2024. |
| Reparability Index (for France) | 7.9 |
