Description
| Quick Specs: | • Processor - AMD Ryzen™ 7 5700U • Graphics - AMD Radeon™ Graphics • Memory - DDR4 8GB • Storage - 512GB M.2 NVMe™ PCIe® 3.0 SSD • Resolution - (1920 x 1080) • Panel size - 15.6-inch • Battery - 42WHrs, 3S1P, 3-cell Li-ion |
||
Full Specs:
| Part No | 90NB0TP1-M08010 |
| Model Name | M513UA-L1301WS |
| EAN Code | 4711081476405 |
| UPC Code | 195553476409 |
| Operating System | Windows 11 Home - ASUS recommends Windows 11 Pro for business |
| Office | Office Home and Student 2021 included |
| LCD cover-material | Aluminum |
| LCD cover-color | Indie Black |
| Top case-material | Plastic |
| Top case-color | Black |
| Bottom case-material | Plastic |
| Bottom case-color | Black |
| Military grade | N/A |
| Touch Panel | Non-touch screen |
| Panel Size | 15.6-inch |
| Resolution | FHD (1920 x 1080) OLED 16:9 aspect ratio |
| Response time | 0.2ms response time |
| Refresh rate | 60Hz refresh rate |
| Peak Brightness | 600nits HDR peak brightness |
| Color gamut | 100% DCI-P3 color gamut |
| Contrast ratio | 1,000,000:1 |
| VESA CERTIFIED Display HDR | VESA CERTIFIED Display HDR True Black 600 |
| Color depth | 1.07 billion colors |
| Pantone | PANTONE Validated |
| Glare | Glossy display |
| Low blue light | 70% less harmful blue light |
| SGS Eye Care Display | SGS Eye Care Display |
| Screen-to-body ratio | 85 ％ |
| Processor | AMD Ryzen™ 7 5700U Mobile Processor (8-core/16-thread, 12MB cache, up to 4.3 GHz max boost) |
| Chipset | N/A |
| Discrete/Share | Share |
| Intergrated GPU | AMD Radeon™ Graphics |
| VRAM | N/A |
| How to upgrade memory | Upgradable; Need to remove bottom/top case |
| Expansion Slot(includes used) | 1x DDR4 SO-DIMM slot 1x STD 2.5” SATA HDD |
| On board memory | 8GB DDR4 on board |
| Total System Memory | DDR4 8GB |
| Storage | 512GB M.2 NVMe™ PCIe® 3.0 SSD |
| Front-facing camera | 720p HD camera |
| Wireless | Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth 5 |
| 3G/4G | N/A |
| ScreenPad? | N/A |
| FingerPrint | FingerPrint |
| I/O ports | 1x USB 3.2 Gen 1 Type-A 1x USB 3.2 Gen 1 Type-C 2x USB 2.0 Type-A 1x HDMI 1.4 1x 3.5mm Combo Audio Jack 1x DC-in Micro SD card reader |
| Audio | Built-in speaker Built-in microphone harman/kardon (Mainstream) |
| Voice control | with Cortana support |
| AC Adapter | ø4.0, 65W AC Adapter, Output: 19V DC, 3.42A, 65W, Input: 100~240V AC 50/60Hz universal |
| Battery | 42WHrs, 3S1P, 3-cell Li-ion |
| Replaceable Battery | No |
| Keyboard type | Backlit Chiclet Keyboard with Num-key |
| Dimension (WxHxD) | 35.98 x 23.53 x 1.86 ~ 1.86 cm |
| Weight (with Battery) | 1.80 kg |
| Weight (without Battery) | 1.70 kg |
