Description
| Quick Specs: | • Processor - Intel® Core™ i5-11300H Processor 3.1 GHz • Graphics - NVIDIA® GeForce RTX™ 3060 Laptop GPU • Memory - 8GB DDR4 on board + 8GB DDR4-3200 SO-DIMM • Storage - 512GB PCIe® 3.0 NVMe™ M.2 SSD • Resolution - HD (1920 x 1080) 16:9 • Panel size - 15.6-inch • Battery - 76WHrs, 4S1P, 4-cell Li-ion |
||
Full Specs:
| Part No | 90NR05X1-M05640 |
| Model Name | FX516PM-AZ160T |
| EAN Code | 4711081253341 |
| UPC Code | 195553253345 |
| Marketing Name | ASUS TUF Dash F15 |
| Color | Eclipse Gray |
| Dimension (W x D x H) | 36.0 x 25.2 x 1.99 ~ 1.99 cm |
| Weight | 2.00 Kg |
| Processor | Intel® Core™ i5-11300H Processor 3.1 GHz (8M Cache, up to 4.4 GHz, 4 cores) |
| Chipset | N/A |
| Discrete/Optimus | Optimus |
| Graphic | NVIDIA® GeForce RTX™ 3060 Laptop GPU |
| Graphic Wattage | With ROG Boost up to 1525MHz at 80W (85W with Dynamic Boost) |
| Graphic Memory | 6GB GDDR6 |
| IGPU | Intel® Iris Xᵉ Graphics (Intel® Iris Xᵉ Graphics in Dual Channel Intel® UHD Graphics in Single Channel) |
| Panel Size | 15.6-inch |
| Resolution | FHD (1920 x 1080) 16:9 |
| Refresh Rate | 240Hz |
| Viewing Angle | 85/85/85/85 |
| Panel Tech | IPS-level |
| Brightness | 300nits |
| Contrast | 1000:1 |
| NTSC % | 72% |
| SRGB % | 100% |
| Adobe % | 75.35% |
| Anti glare | anti-glare display |
| Adaptive-Sync technology | Adaptive-Sync |
| Pantone | N/A |
| Support Dolby Vision HDR | N/A |
| Total System Memory | 8GB DDR4 on board + 8GB DDR4-3200 SO-DIMM |
| On board memory | 8GB DDR4 on board |
| Memory Slot | 1x SO-DIMM slot |
| DIMM Memory | 8GB DDR4-3200 SO-DIMM |
| Memory Max. | 32GB |
| System Storage Installed | 512GB PCIe® 3.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe | 2 |
| M.2 SSD Support List | M.2 512GB PCIe SSD M.2 1TB PCIe SSD |
| Expansion Slot (includes used) | 1x DDR4 SO-DIMM slot 2x PCIe |
| LAN | 10/100/1000 Mbps |
| Wi-Fi/Bluetooth | Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth 5.2 (*BT version may change with OS version different.) |
| I/O Ports | 1x RJ45 LAN port 1x Thunderbolt™ 4 support DisplayPort™ / power delivery 3x USB 3.2 Gen 1 Type-A |
| Display output | 1x HDMI 2.0b |
| Audio | 1x 3.5mm Combo Audio Jack |
| Webcam | N/A |
| Mic | Built-in array microphone |
| Keyboard Type | Backlit Chiclet Keyboard Single Light |
| NumberPad | N/A |
| Aura Sync | N/A |
| Speakers | 2-speaker system |
| Audio Tech | DTS software |
| Operating System | Windows 10 Home - ASUS recommends Windows 11 Pro for business |
| Security | BIOS Administrator Password and User Password Protection Kensington Nano Security Slot™ Trusted Platform Module (Firmware TPM) |
| Battery | 76WHrs, 4S1P, 4-cell Li-ion |
| Power | ø6.0, 200W AC Adapter, Output: 20V DC, 10A, 200W, Input: 100-240V AC, 50/60Hz universal |
| Reparability Index (for FR) | 6.5 |
