| Model |
RT-AX53U |
| Network Standard |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g |
|
WiFi 4 (802.11n) |
|
WiFi 5 (802.11ac) |
|
WiFi 6 (802.11ax) |
|
IPv4, IPv6 |
| Product Segment |
AX1800 ultimate AX performance: 1201 Mbps + 574 Mbps |
| WiFi Data Rate |
|
| 802.11a |
Up to 54 Mbps |
| 802.11b |
Up to 11 Mbps |
| 802.11g |
Up to 54 Mbps |
| WiFi 4 (802.11n) |
Up to 300 Mbps |
| WiFi 5 (802.11ac) |
Up to 867 Mbps |
| WiFi 6 (802.11ax) (2.4GHz) |
Up to 574 Mbps |
| WiFi 6 (802.11ax) (5GHz) |
Up to 1201 Mbps |
| Antenna |
External Antennas × 4 |
| Transmit / Receive |
2.4GHz: 2×2 |
|
5GHz: 2×2 |
| Processor |
Dual-core (4 VPE) |
| Memory |
128 MB Flash |
|
256 MB RAM |
| Boosts Speed |
OFDMA (Orthogonal Frequency Division Multiple Access) |
|
Beamforming: standard-based and universal |
|
1024-QAM high data rate |
|
20/40/80 MHz bandwidth |
| Operating Frequency |
2.4GHz / 5GHz |
| Operating Mode |
Access Point, Media Bridge, Repeater, Router |
| I/O Ports |
RJ45 for Gigabit BaseT WAN × 1 |
|
RJ45 for Gigabit BaseT LAN × 3 |
|
USB Port × 1 |
| Buttons |
WPS Button, Reset Button, Power Switch |
| LED Indicators |
Power × 1 |
|
2.4GHz × 1 |
|
5GHz × 1 |
|
LAN × 3 |
|
WAN × 1 |
|
USB × 1 |
| Power Supply |
AC Input: 100V ~ 240V (50 ~ 60Hz) |
|
DC Output: 12V, max. 1.5A current |
| Package Content |
RT-AX53U |
|
RJ45 cable × 1 |
|
Adapter × 1 |
|
Quick Start Guide (QSG) × 1 |
|
Warranty Card × 1 |
| Product Weight |
346g |
| Product Dimensions |
190 × 126 × 45 mm |
| AiMesh |
AiMesh |
|
Primary AiMesh Router |
|
AiMesh Node |
| Parental Control |
Block access to unwanted websites and apps |
| Customized Internet Schedule |
Yes |
| Guest Network |
Internet access for guests with local network restrictions |
| Security |
Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA3-Personal |
|
WPS, Let's Encrypt, SSH, Firewall |
|
AiProtection: Malicious Site Blocking |
|
Infected Device Prevention and Blocking |
| VPN |
Instant Guard |
|
VPN Client: L2TP, OpenVPN, PPTP |
|
VPN Server: IPSec, OpenVPN, PPTP |
| Traffic Control |
Bandwidth Limiter |
|
Traditional QoS |
|
Traffic Monitor: Real-time, Wired, Wireless |
| WAN |
Internet Connection Types: PPPoE, PPTP, L2TP, Automatic IP, Static IP |
|
Dual WAN |
|
3G / 4G LTE dongle support |
|
Port triggering, DMZ, DDNS |
| LAN |
DHCP Server |
|
IGMP Snooping |
|
IPTV Support |
|
Manually Assign IP Address |
|
Wake on LAN (WOL) |
| Wireless Features |
UTF-8 SSID |
|
WiFi MAC Address Filter |
|
Wireless Scheduler |
|
Airtime Fairness |
|
RADIUS Client |
|
Universal and Explicit Beamforming |
| USB Applications |
Safely Remove Disk |
|
Download Master |
|
AiDisk |
|
Media Server |
|
Samba Server |
|
FTP Server |
|
Shared Folder Privileges |
| Administration |
Configuration Backup and Restore |
|
Diagnosis tools |
|
Feedback System |
|
System Log |
