| Part No |
90NR08A5-M000K0 |
| Model Name |
G513RC-HN016W |
| |
|
| EAN Code |
4711081647324 |
| UPC Code |
195553647328 |
| |
|
| Marketing Name |
ROG Strix G15 |
| Color |
Eclipse Gray |
| Dimension (W x D x H) |
35.4 x 25.9 x 2.06 ~ 2.59 cm |
| Weight |
2.10 Kg |
| Processor |
AMD Ryzen™ 7 6800H/HS Mobile Processor (8-core/16-thread, 20MB cache, up to 4.7 GHz max boost) |
| Chipset |
N/A |
| Discrete/Optimus |
MUX Switch + Optimus |
| Graphic |
NVIDIA® GeForce RTX™ 3050 Laptop GPU |
| Graphic Wattage |
ROG Boost: 1550MHz* at 95W (1500MHz Boost Clock+50MHz OC, 80W+15W Dynamic Boost) |
| Graphic Memory |
4GB GDDR6 |
| IGPU |
AMD Radeon™ Graphics |
| Panel Size |
15.6-inch |
| Resolution |
FHD (1920 x 1080) 16:9 |
| Refresh Rate |
144Hz |
| Viewing Angle |
170 |
| Panel Tech |
Value IPS-level |
| Brightness |
250nits |
| Contrast |
1:1000 |
| NTSC % |
45% |
| SRGB % |
62.5% |
| Adobe % |
47.34% |
| Anti glare |
Anti-glare display |
| Adaptive-Sync technology |
Adaptive-Sync |
| Pantone |
N/A |
| Support Dolby Vision HDR |
N/A |
| On board memory |
N/A |
| DIMM Memory |
8GB DDR5-4800 SO-DIMM |
| Total System Memory |
DDR5 8GB |
| Memory Slot |
2x SO-DIMM slots |
| Memory Max. |
32GB |
| Multi-channel memory technology |
Support dual channel memory |
| System Storage Installed |
512GB PCIe® 4.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe |
2 |
| M.2 SSD Support List |
M.2 512GB PCIe
M.2 1TB PCIe |
| Expansion Slot (includes used) |
2x DDR5 SO-DIMM slots
2x PCIe |
| LAN |
10/100/1000/2500 Mbps |
| On board Wireless |
N/A |
| Wi-Fi/Bluetooth |
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.2 (*Bluetooth® version may change with OS version different.) -RangeBoost |
| I/O Ports |
1x 2.5G LAN port
1x USB 3.2 Gen 2 Type-C
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery / G-SYNC
2x USB 3.2 Gen 1 Type-A |
| Display output |
1x HDMI 2.1 TMDS |
| Audio |
1x 3.5mm Combo Audio Jack |
| Mic |
Built-in array microphone |
| Keyboard Type |
Backlit Chiclet Keyboard 4-Zone RGB |
| NumberPad |
N/A |
| Aura Sync |
Yes |
| Speakers |
2-speaker system |
| Audio Tech |
AI noise-canceling technology
Dolby Atmos
Hi-Res certification |
| Operating System |
Windows 11 Home |
| Antivirus |
MCAFEE_30D |
| Xbox Game Pass |
Xbox Game Pass for PC_1 month (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) |
| Security |
BIOS Administrator Password and User Password Protection
Trusted Platform Module (Firmware TPM) |
| Battery |
56WHrs, 4S1P, 4-cell Li-ion |
| Power |
ø6.0, 200W AC Adapter, Output: 20V DC, 10A, 200W, Input: 100-240V AC, 50/60Hz universal |
| Bundled Peripherals |
ROG backpack |
| Additional Accessories |
ROG Impact Gaming Mouse
TYPE-C, 100W AC Adapter, Output: 20V DC, 5A, 100W, Input: 100~240V AC 50/60Hz universal |
| Reparability Index (for FR) |
7.0 |
