Description
Lead time | Usually in Stock |
---|
Run time for load
WMin-max: 42-415 W
|
0min 53s |
---|---|
|
|
Main Input Voltage | 230 V |
Rated power in W | 415 W |
Rated power in VA | 800 VA |
output connection type | 1 IEC 60320 C13 2 universal receptacle |
Cable length | 1.22 m |
Number of cables | 1 |
Battery type | Lead-acid battery |
Run Time | View Runtime Graph |
---|---|
Efficiency | View Efficiency Graph |
Number of battery filled slots | 1 |
Number of battery free slots | 0 |
Battery recharge time | 6 h |
Battery charger power | 13 W rated |
Battery life | 2…4 year(s) |
Replacement battery | APCRBC110 |
Extended runtime | 0 |
Provided equipment | User manual warranty card |
---|---|
product web sub-family | Entry level |
Number of power module free slots | 0 |
Number of power module filled slots | 0 |
Redundant | No |
Colour | Black |
---|---|
height | 20 cm |
Width | 11.5 cm |
Depth | 25.6 cm |
Net weight | 6.5 kg |
Mounting preference | No preference |
Mounting mode | Not rack-mountable |
Two post mountable | 0 |
USB compatible | No |
Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
---|---|
Input voltage limits | 140...300 V |
Maximum input current | 7 A |
Switching current capacity | 7 A |
Input protection type | 3-pole circuit breaker |
Input current | 7 A (1 phase) |
Input Power Factor at Full Load | 0.52 |
Maximum configurable power in W | 415 W |
---|---|
Output frequency | 50/60 Hz +/- 1 Hz sync to mains 50/60 Hz +/- 1 Hz unsynchronised |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
Maximum configurable power in VA | 800 VA |
Transfer time | 4 ms typical : 6 ms maximum |
product certifications | CE |
---|
ambient air temperature for operation | 0…40 °C |
---|---|
Relative humidity | 0…95 % |
Operating altitude | 0...10000 ft |
Ambient air temperature for storage | -15…40 °C |
Storage Relative Humidity | 0…95 % |
Storage altitude | 0.00…9144.00 m |
Acoustic level | 45 dBA |
control panel | LED status display with load and battery bar-graphs and on line : on battery : replace battery : and overload indicators |
---|---|
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge energy rate | 273 J |
---|
Unit Type of Package 1 | PCE |
---|---|
Number of Units in Package 1 | 1 |
Package 1 Height | 29 cm |
Package 1 Width | 34.5 cm |
Package 1 Length | 20.5 cm |
Package 1 Weight | 6.7 kg |
SCC14 | 10731304315183 |
Warranty | 2 years repair or replace |
---|
